Secure Coding With Concurrency in Swift 4

In my previous article about secure coding in Swift, I discussed basic security vulnerabilities in Swift
such as injection attacks. While injection attacks are common, there are other ways your app can be compromised. A common but sometimes-overlooked kind of vulnerability is race conditions.

Swift 4
introduces Exclusive Access to Memory, which consists of a set of
rules to prevent the same area of memory being accessed at the same time.
For example, the inout argument in Swift tells a method that it can
change the value of the parameter inside the method.

But what happens if we pass in the same variable to change at the same time?

Swift 4
has made improvements that prevent this from compiling. But while Swift can find these obvious scenarios at compile
time, it is difficult, especially for performance reasons, to find
memory access problems in concurrent code, and most of
the security vulnerabilities exist in the form of race conditions.

Race Conditions

As soon as you have more than one thread that needs to write to the same data at the same time, a race condition can occur. Race conditions cause data corruption. For these types of attacks, the vulnerabilities are usually more subtle—and the exploits more creative. For instance, there might be the ability to alter a shared resource to change the flow of security code happening on another thread, or in the case of authentication status, an attacker might be able to take advantage of a time gap between the time of check and the time of use of a flag.

The way to avoid race conditions is to synchronize the data. Synchronizing data usually means to “lock” it so that only one thread can access that part of the code at a time (said to be a mutex—for mutual exclusion). While you can do this explicitly using the NSLock class, there is potential to miss places where the code should have been synchronized. Keeping track of the locks and whether they are already locked or not can be difficult.

Grand Central Dispatch

Instead of using primitive locks, you can use Grand Central Dispatch (GCD)—Apple’s modern concurrency API designed for performance and security. You don’t need to think about the locks yourself; it does the work for you behind the scenes.

As you can see, it’s quite a simple API, so use GCD as your first choice when designing your app for concurrency.

Swift’s runtime security checks cannot be performed across GCD threads because it creates a significant performance hit. The solution is to use the Thread Sanitizer tool if you are working with multiple threads. The Thread Sanitizer tool is great at finding problems you might never find by looking at the code yourself. It can be enabled by going to Product > Scheme > Edit Scheme > Diagnostics, and checking the Thread Sanitizer option.

If the design of your app makes you work with multiple threads, another way to protect yourself from the security issues of concurrency is to try to design your classes to be lock free so that no synchronization code is necessary in the first place. This requires some real thought about the design of your interface, and can even be considered a separate art in and of itself!

The Main Thread Checker

It is important to mention that data corruption can also occur if you do UI updates on any thread other than the main thread (any other thread is referred to as a background thread).

Sometimes it’s not even obvious you are on a background thread. For example, NSURLSession‘s delegateQueue, when set to nil, will by default call back on a background thread. If you do UI updates or write to your data in that block, there is a good chance for race conditions. (Fix this by wrapping the UI updates in DispatchQueue.main.async {} or pass in OperationQueue.main as the delegate queue.)

New in Xcode 9 and enabled by default is the Main Thread Checker (Product > Scheme > Edit Scheme > Diagnostics > Runtime API Checking > Main Thread Checker). If your code is not synchronized, issues will show up in the Runtime Issues on the left pane navigator of Xcode, so pay attention to it while testing your app.

To code for security, any callbacks or completion handlers that you write should be documented whether they return on the main thread or not. Better yet, follow Apple’s newer API design which lets you pass a completionQueue in the method so you can clearly decide and see what thread the completion block returns on.

A Real-World Example

Enough talk! Let’s dive into an example.

Here we have no synchronization, but more than one thread accesses the data at the same time. The good thing about Thread Sanitizer is that it will detect a case like this. The modern GCD way to fix this is to associate your data with a serial dispatch queue.

Now the code is synchronized with the .async block. You might be wondering when to choose .async and when to use .sync. You can use .async when your app doesn’t need to wait until the operation inside the block is finished. It might be better explained with an example.

In this example, the thread that asks the transaction array if it contains a specific transaction provides output, so it needs to wait. The other thread doesn’t take any action after appending to the transaction array, so it doesn’t need to wait until the block is completed.

These sync and async blocks can be wrapped in methods that return your internal data, such as getter methods.

Scattering GCD blocks all over the areas of your code that access shared data is not a good practice as it is harder to keep track of all the places that need to be synchronized. It’s much better to try and keep all this functionality in one place.

Good design using accessor methods is one way to solve this problem. Using getter and setter methods and only using these methods to access the data means that you can synchronize in one place. This avoids having to update many parts of your code if you are changing or refactoring the GCD area of your code.


While single stored properties can be synchronized in a class, changing properties on a struct will actually affect the entire struct. Swift 4 now includes protection for methods that mutate the structs.

Let’s first look at what a struct corruption (called a “Swift access race”) looks like.

The two methods in the example change the stored properties, so they are marked mutating. Lets say thread 1 calls begin() and thread 2 calls finish(). Even if begin() only changes id and finish() only changes timestamp, it’s still an access race. While normally it’s better to lock inside accessor methods, this doesn’t apply to structs as the entire struct needs to be exclusive.

One solution is to change the struct to a class when implementing your concurrent code. If you needed the struct for some reason, you could, in this example, create a Bank class which stores Transaction structs. Then the callers of the structs inside the class can be synchronized.

Here is an example:

Access Control

It would be pointless to have all this protection when your interface exposes a mutating object or an UnsafeMutablePointer to the shared data, because now any user of your class can do whatever they want with the data without the protection of GCD. Instead, return copies to the data in the getter. Careful interface design and data encapsulation are important, especially when designing concurrent programs, to make sure that the shared data is really protected.

sure the synchronized variables are marked
private, as opposed to open or public, which would allow members
from any source file to access it. One
interesting change in Swift 4 is that the
private access level scope is expanded to
be available in extensions.
Previously it could only be
used within the enclosing declaration, but in Swift 4, a private variable can be
accessed in an extension,
as long as the extension
of that declaration is in the same source file.

Not only are variables at risk for data corruption but files as well. Use the FileManager Foundation class, which is thread-safe, and check the result flags of its file operations before continuing in your code.

Interfacing With Objective-C

Many Objective-C objects have a mutable counterpart depicted by their
title. NSString‘s mutable version is named NSMutableString, NSArray‘s is
NSMutableArray, and so on. Besides the fact that
these objects can be mutated outside of synchronization, pointer
types coming from Objective-C also subvert Swift optionals. There is
a good chance that you could be expecting an object in Swift, but from
Objective-C it is returned as nil.

If the app crashes, it gives valuable insight into the internal logic. In this case, it could be that user input was not properly checked and that area of the app flow is worth looking at to try and exploit.

solution here is to update your Objective-C code to include
nullability annotations. We can take a slight diversion here as this advice applies to safe interoperability in general, whether between Swift and Objective-C or between two other programming languages.

Preface your Objective-C
variables with nullable when nil
can be returned, and nonnull when it shouldn’t.

You can also add nullable
and nonnull to the attribute list of Objective-C properties.

Static Analyzer tool in Xcode has always been great for finding
Objective-C bugs. Now with nullability annotations, in Xcode 9 you can use the Static Analyzer on your
Objective-C code
and it will find nullability
inconsistencies in your file. Do this by navigating to
Product > Perform Action > Analyze.

While it’s enabled by default, you can also control the nullability checks in
LLVM with -Wnullability* flags.

checks are good for finding issues at compile time, but they don’t
find runtime issues. For example, sometimes we assume in a part of
our code that an optional value will always exist and use the force
unwrap ! on it. This is an implicitly unwrapped optional, but there is really no guarantee that it will always exist. After all, if it
were marked optional, it’s likely to be nil at some point. Therefore,
it’s a good idea to avoid force unwrapping with !. Instead, an elegant
solution is to check at runtime like so:

To further help you out, there
is a new feature added in Xcode 9 to perform nullability checks at runtime.
It is part of the Undefined Behavior Sanitizer, and while it’s not enabled
by default, you can enable it by going to Build Settings >
Undefined Behavior Sanitizer
and setting Yes for Enable Nullability
Annotation Checks


It’s good practice to write your methods with only one entry and one exit point. Not only is this good for readability, but also for advanced multithreading support.

Let’s say a class was designed without concurrency in mind. Later the requirements changed so that it must now support the .lock() and .unlock() methods of NSLock. When it comes time to place locks around parts of your code, you may need to rewrite a lot of your methods just to be thread-safe. It’s easy to miss a return hidden in the middle of a method that was later supposed to lock your NSLock instance, which can then cause a race condition. Also, statements such as return will not automatically unlock the lock. Another part of your code that assumes the lock is unlocked and tries to lock again will deadlock the app (the app will freeze and eventually be terminated by the system). Crashes can also be security vulnerabilities in multithreaded code if temporary work files are never cleaned up before the thread terminates. If your code has this structure:

You can instead store the Boolean, update it along the way and then return it at the end of the method. Then synchronization code can easily be wrapped in the method without much work.

The .unlock() method must be called from the same thread that called .lock(),  otherwise it results in
undefined behavior.


Often, finding and fixing vulnerabilities in concurrent code comes down to
bug hunting. When you find a bug, it's like holding a mirror up to
yourself—a great learning opportunity. If you
forgot to synchronize in one place, it's likely that the same mistake
is elsewhere in the code. Taking the time to check the rest of your
code for the same mistake when you encounter a bug is a very
efficient way of preventing security vulnerabilities that would keep
appearing over and over again in future app releases.

In fact, many of
the recent iOS jailbreaks have been because of repeated coding
mistakes found in Apple's IOKit. Once you know the developer's style, you can check other parts of the code for similar bugs.

Bug finding is good motivation for code
reuse. Knowing that you fixed a problem in one place and don't have to go
find all the same occurrences in copy/paste code can be a big relief.

conditions can be complicated to find during testing because memory might have to be
corrupted in just the “right way” in order to see the problem, and sometimes the problems appear a long time later in the app's execution.

When you are testing,
cover all your code. Go through each flow and case and test each line
of code at least once. Sometimes it helps to input random data (fuzzing the inputs), or choose extreme values in hopes of finding an edge case that would not be
obvious from looking at the code or using the app in a normal way. This, along with the new Xcode tools available, can go a long way towards preventing
security vulnerabilities. While no code is 100% secure, following
a routine, such as early-on functional tests, unit tests, system
test, stress and regression tests, will really pay off.

Beyond debugging your app, one thing that is different for the release configuration (the
configuration for apps
published on the store) is that code optimizations are included. For
example, what the compiler thinks is an unused operation can get optimized out, or a variable may not stick
around longer than necessary in a concurrent block. For your published
app, your code is actually changed, or different from the one that you
tested. This means that bugs can be
introduced that only exist once you release your app.

If you are not
using a test configuration, make sure you test your app on release mode
navigating to Product > Scheme > Edit Scheme. Select Run from
the list on the left, and in the Info pane on the right, change Build
to Release. While it's good to cover your entire app in
this mode, know that because of optimizations, the breakpoints and
the debugger will not behave as expected. For example,
variable descriptions might not be available even though the code is
executing correctly.


In this post, we looked at race conditions and how to avoid them by coding securely and using tools like the Thread Sanitizer. We also talked about Exclusive
Access to Memory, which is a great addition to Swift 4. Make sure it's set
to Full Enforcement in Build Settings > Exclusive
Access to Memory

Remember that these enforcements are only on for debug
mode, and if you are still using Swift 3.2, many of the
enforcements discussed come in the form of warnings only. So take the warnings seriously, or
better yet, make use of all the new features available by adopting Swift 4 today!
